Descrição
Processor
Intel Core i3-12100, 4C (4P + 0E) / 8T, P-core 3.3 / 4.3GHz, 12MB
Graphics
Integrated Intel UHD Graphics 730
Chipset
Intel B660
Memory
1x 8GB UDIMM DDR4-3200
Memory Slots
Two DDR4 UDIMM slots, dual-channel capable
Max Memory
Up to 64GB DDR4-3200
Storage
256GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
Optane Memory
None
Storage Support
Up to two drives, 1x 2.5"/3.5" HDD + 1x M.2 SSD
• 2.5" HDD up to 1TB
• 3.5" HDD up to 2TB
• M.2 SSD up to 1TB
Card Reader
None
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek ALC623-CG codec
Speakers
1Wx1
Power Supply
180W 85%
DESIGN
Keyboard
USB Traditional Keyboard, Black, Portuguese (Brazil)
Mouse
USB Calliope Mouse, Black
Expansion Slots
One PCIe 3.0 x1, low-profie (length < 167.65mm, height < 68.90mm)
One PCIe 4.0 x16, low-profie (length < 167.65mm, height < 68.90mm)
Two M.2 slots (one for WLAN, one for SSD)
Case Color
Black
Stand
None
Form Factor
SFF (7.4L)
Dimensions (WxDxH)
100 x 308 x 274.8 mm (3.9 x 12.1 x 10.8 inches)
Weight
Around 4.5 kg (9.9 lbs)
CONNECTIVITY
Ethernet
Integrated 100/1000M
WLAN + Bluetooth
None
Front Ports
2x USB 3.2 Gen 1
1x USB-C 3.2 Gen 1 (support data transfer and 5V@3A charging)
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)
Rear Ports
2x USB 2.0
2x USB 3.2 Gen 1 (one supports Smart Power On)
1x VGA
1x HDMI 2.1 TMDS
1x DisplayPort 1.4
1x Ethernet (RJ-45)
1x line-out (3.5mm)
Optional Rear Ports (configured)
None
Monitor Cable
None
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0, TCG certified
Fingerprint Reader
No fingerprint reader
Physical Locks
Kensington Security Slot, 3 x 7 mm
Padlock Loop
Kensington Cable Lock
None
Smart Cable Clip
None
Chassis Intrusion Switch
Chassis Intrusion Switch
SERVICE
Base Warranty
None
Included Upgrade
1Y Premier Support upgrade from 0 base warranty (5WS1F68981)
CERTIFICATIONS
Green Certifications
ErP Lot 3
TCO Certified 9.0
RoHS compliant
SOFTWARE
Operating System
Windows 11 Pro 64, Portuguese (Brazil)Processor
Intel Core i3-12100, 4C (4P + 0E) / 8T, P-core 3.3 / 4.3GHz, 12MB
Graphics
Integrated Intel UHD Graphics 730
Chipset
Intel B660
Memory
1x 8GB UDIMM DDR4-3200
Memory Slots
Two DDR4 UDIMM slots, dual-channel capable
Max Memory
Up to 64GB DDR4-3200
Storage
256GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
Optane Memory
None
Storage Support
Up to two drives, 1x 2.5/3.5 HDD + 1x M.2 SSD
• 2.5 HDD up to 1TB
• 3.5 HDD up to 2TB
• M.2 SSD up to 1TB
Card Reader
None
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek ALC623-CG codec
Speakers
1Wx1
Power Supply
180W 85%
DESIGN
Keyboard
USB Traditional Keyboard, Black, Portuguese (Brazil)
Mouse
USB Calliope Mouse, Black
Expansion Slots
One PCIe 3.0 x1, low-profie (length < 167.65mm, height < 68.90mm)
One PCIe 4.0 x16, low-profie (length < 167.65mm, height < 68.90mm)
Two M.2 slots (one for WLAN, one for SSD)
Case Color
Black
Stand
None
Form Factor
SFF (7.4L)
Dimensions (WxDxH)
100 x 308 x 274.8 mm (3.9 x 12.1 x 10.8 inches)
Weight
Around 4.5 kg (9.9 lbs)
CONNECTIVITY
Ethernet
Integrated 100/1000M
WLAN + Bluetooth
None
Front Ports
2x USB 3.2 Gen 1
1x USB-C 3.2 Gen 1 (support data transfer and 5V@3A charging)
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)
Rear Ports
2x USB 2.0
2x USB 3.2 Gen 1 (one supports Smart Power On)
1x VGA
1x HDMI 2.1 TMDS
1x DisplayPort 1.4
1x Ethernet (RJ-45)
1x line-out (3.5mm)
Optional Rear Ports (configured)
None
Monitor Cable
None
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0, TCG certified
Fingerprint Reader
No fingerprint reader
Physical Locks
Kensington Security Slot, 3 x 7 mm
Padlock Loop
Kensington Cable Lock
None
Smart Cable Clip
None
Chassis Intrusion Switch
Chassis Intrusion Switch
SERVICE
Base Warranty
None
Included Upgrade
1Y Premier Support upgrade from 0 base warranty (5WS1F68981)
CERTIFICATIONS
Green Certifications
ErP Lot 3
TCO Certified 9.0
RoHS compliant
SOFTWARE
Especificações Técnicas
Conheça o produto
Este produto ainda não tem descrição cadastrada.
Grátis
